sovol-sv03 legacy – Спецификации и настройки

Спецификации

• Производител: Sovol 3D
• Технология: FDM
• Клас: experimenter

Чести проблеми и решения

Stringing

Thin plastic threads forming between separate elements of the printed part, most often due to wet hygroscopic filament or insufficient retraction. Решение: Dry the filament (e.g., 4-6 hours at 50°C for PLA), increase the retraction distance by 1-2 mm, reduce the nozzle temperature by 5°C, and increase the travel speed to 200 mm/s.

Warping

The corners or edges of the print detach from the platform and curl upwards due to uneven thermal contraction and poor adhesion. Решение: Increase the bed temperature by 5°C, add a Brim (5-10 mm contour), use an adhesive such as glue on the glass/PEI surface, and reduce the part cooling fan for the initial layers.

Under-extrusion / Clogging

Thin, brittle walls, structural gaps, or a complete halt of extrusion due to partial clogging or incorrect extruder steps. Решение: Perform a ‘Cold pull’ (with Nylon at 240°C dropping to 100°C) for hardware unclogging, check the tension of the Direct Drive extruder, and calibrate the E-steps via the M92 command.
